Vents Frigate 120 Series EC Motor Energy Recovery Ventilators
Vents Frigate 120 Series EC Motor Energy Recovery Ventilators
In stock
Manufacturer Direct. Orders ship same day with free shipping included!
Couldn't load pickup availability
The Frigate 120 ERV EC equipped units are outfitted with highly efficient electronically commutated (EC) motors, boasting an external rotor and backward-curved blade impeller.
These EC motors deliver exceptional performance and offer a wide range of speed control options. Furthermore, both the electric motors and impellers are meticulously balanced to ensure optimal operation. 2 year warranty. An ideal solution for homes, apartments, cottages, tiny homes and passive houses.
Features
- Enthalpy recovery core
- MERV 6 supply + exhaust filters
- Up to 161 CFM
- Recovery efficiency up to 62%
- Fan Efficacy 2.78 CFM/W
- Sound level - 1.5 sones
- 5" Duct diameter
- Slim casing - 9 5/8"
- 10 Year warranty on Core
Need assistance? Call us at 1-833-878-3687, Mon-Fri, 9 am to 5 pm (EST).
Details
Frigate 120 EC Series ERV | |||
120 EC | 120R EC | 120CF EC | |
Maximum continuous air flow capacity (at 0.1 in. w.g.) | 161 CFM | 150 CFM | 161 CFM |
Sensible recovery efficiency at 32°F (0`C) | 71% | 72% | 71% |
MERV6 supply/exhaust filters | Yes | Yes | Yes |
Sound level | 1.5 Sones | ||
Power consumption | 175 W | 175 W | 175 W |
Fan Efficacy | 2.83 CFM/W | ||
Duct diameters | 5 inches | ||
Dimensions (H x W x D) | 9 5/8”x 23 7/8” x 26 1/2” |
Frigate EC Motor Model Comparison
Frigate EC Model | 80 EC | 80 R EC | 120EC | 120 R EC | 120 ERV EC | 120 ERV REC | 150EC HRV | 150 R EC HRV | ERV 150 EC | ERV 150 R EC |
Maximum continuous air flow capacity (at 0.1 in. w.g.) | 81 CFM | 189 CFM | 161 CFM | 150 CFM | 186 CFM | 181 CFM | ||||
Sensible recovery efficiency at 32°F (0`C) | 73% | 62% | 71% | 72% | 69% | 73% | ||||
Apparent Sensible Effectiveness at 32°f (0`C) | 82% | 69% | 73% | 74% | 78% | 82% | ||||
MERV6 supply/exhaust filters | Yes - All Models - Washable and replaceable | |||||||||
Sound level | 1.4 Sones | 1.9 Sones | 1.5 Sones | 2.1 Sones | 1.9 Sones | |||||
Fan efficacy | 1.72 CFM/W | 2.86 CFM/W | 2.78 CFM/W | 2.83 CFM/W | 2.56 CFM/W | |||||
Power consumption | 61 W | 204 W | 175 W | 186 W | 186 W | |||||
Recovery core | Enthalpy | Polystyrene cross-flow | Enthalpy | Polystyrene cross-flow | Enthalpy | |||||
Duct diameters | 5" Duct diameter | |||||||||
Dimensions (H x W x D) | 9 1/8”x 20 1/8” x 21 1/8” | 9 5/8”x 23 7/8” x 26 1/2” | 9 5/8”x 25 1/8” x 27 3/4” | |||||||
Fan defrost | Yes | Yes | Yes | Yes | Yes | |||||
Recirculation | Yes | Yes | Yes | Yes | Yes |
Downloads
The right Frigate/Brig for your home
Frigate/Brig Model | Max CFM | Recommended House Size |
Series 80 | 93 | up to 1900 sq ft |
Series 120 | 127 | up to 2700 sq ft |
Series 150 | 178 | up to 3700 sq ft |
Brig 200 | 213 | up to 4500 sq ft |
Brig 300 | 257 | up to 5200 sq ft |
based on a dwelling with 9' ceilings. Check with your HVAC technician/installer for the most accurate data.
* Max CFM values can vary slightly between the ERV or HRV version in that series.
Download infographic - Vents CFM calculator
Certifications
